Płyta MSI MAG Z890 TOMAHAWK WIFI /Z890/DDR5/SATA3/M.2/TB4/WiFi/BT/PCIe5.0/s.1851/ATX
Dane techniczne
Marka
EAN
4711377259712
Kod producenta
MAG Z890 TOMAHAWK WIFI
Obsługiwane typy procesorów
Intel Core Ultra Processors (series 2)
Uwagi do karty dźwiękowej
Supports up to 32-Bit/384 kHz playback on front panel
Uwagi do karty graficznej
Support HDMITM 2.1 with FRL port, maximum resolution of 8K 60Hz,Thundebolt 4 ports supporting DisplayPort 1.4 with HBR3 over USB Type-C,,with a maximum resolution of 8K@60Hz,Graphics specifications may vary depending on the CPU installed
Zintegrowana karta dźwiękowa
Realtek® ALC4082 Codec + ESS9219Q Combo DAC/HPA
Chipset
Intel® Z890
Gniazda karty graficznej
HDMI,2x Thunderbolt™ 4 (USB Type-C®)
Gniazda karty dźwiękowej
Wewnętrzne gniazdo audio przedniego panelu,2x Audio Jack,Wyjście optyczne S/PDIF
Maksymalna wielkość pamięci
256 GB
Opakowanie
BOX
Inne porty i gniazda
Thunderbolt 5 card connector(JTBT5, support RTD3),Front Type-C Quick Charge Connector(PD_PWR1),2x Combo Fan (Pump_Sys Fan),5x System Fan,EZ Conn-header (JAF_2),2x Front Panel,Chassis Intrusion (JCI),Water Flow connector,Slow mode booting jumper,2x Thermal
Thunderbolt 5 card connector(JTBT5, support RTD3),Front Type-C Quick Charge Connector(PD_PWR1),2x Combo Fan (Pump_Sys Fan),5x System Fan,EZ Conn-header (JAF_2),2x Front Panel,Chassis Intrusion (JCI),Water Flow connector,Slow mode booting jumper,2x Thermal
Baza SCIP
Nie
Wymiary [S x W] (mm)
243,84 x 304,8
Port LAN
1x 10 Gigabit LAN Marvell® AQC113CS
Port Wi-Fi
IEEE 802.11a/b/g/n/ac/ax/be
Port Bluetooth
Bluetooth V5.4
Ilość złącz pamięci DDR5
4
Tryb pracy pamięci RAM
Dual Channel
Uwagi do pamięci RAM
Max. overclocking frequency:,- 1DPC 1R Max speed up to 9200+ MT/s,- 1DPC 2R Max speed up to 7200+ MT/s,- 2DPC 1R Max speed up to 4800+ MT/s,- 2DPC 2R Max speed up to 4800+ MT/s,Supports Intel POR Speed and JEDEC Speed,Supports Memory Overclocking and Inte
Zintegrowany kontroler SATA
Chipset+CPU: 4x SATA III 6Gb/s + 5x M.2
Uwagi do kontrolera SATA
- M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 ,,supports 2280/2260 devices,- M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 ,,supports 2280/2260 devices,- M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 ,,supports 2280/2260 devices,- M.2
Złącza PCI Express x16
3
Uwagi do złącz PCI
- PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU),- PCI_E2 Gen PCIe 5.0 supports up to x8 (From CPU),- PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset),- PCI_E1 support manual BIOS adjustment to X8+X8/X8+X4+X4,- PCI_E2 support manual BIOS adjustment
Maksymalna ilość portów USB 2.0
4
Maksymalna ilość portów USB 3.x
18
Porty USB na panelu tylnym
11x USB 3.1 + 2x USB 3.1 Type-C
Gniazda USB na płycie głównej
2x USB 2.0 (2 porty) + 2x USB 3.0 (4 porty) + USB 3.2 Type-C (1 port)
Port PS/2
Brak
Port szeregowy (COM)
Brak
Port równoległy (LPT)
Brak
Uwagi do WiFi / BT
Intel® Killer™ BE1750x Wi-Fi 7,The Wireless module is pre-installed in the M.2 (Key-E) slot,Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps,Supports 802.11 a/ b/ g/ n/ ac/ ax/ be,Supports Bluetooth® 5.4**, MLO, 4KQAM,6GHz band support
Format płyty
ATX
Gniazdo procesora
Socket 1851
Cechy
Z890 TOMAHAWK WIFI
